The Zone Offroad 6-inch Lift Kit for 2013–2018 Ram 1500 4x4 trucks delivers aggressive stance, larger tire clearance, and OE-quality engineering for both on- and off-road performance. Designed by our team of engineers in Coldwater, Michigan to OE standards, this system features heavy-duty steering knuckles that are cast in the USA, while all fabricated steel components are locally manufactured and powder coated for long-lasting durability and corrosion resistance. The 6-inch lift allows clearance for up to 37 x 12.50 tires on wheels with 4.5 inches of backspacing, giving your Ram a commanding presence and enhanced capability. This kit also offers multiple configuration options to fit your build. Up front, you can choose OE strut spacers that retain the factory front struts and pair them with either Zone Nitro twin-tube rear shocks or upgrade to FOX 2.0 Adventure Series rear shocks for improved performance. For a complete bolt-in solution, Zone Nitro loaded struts are also available and come preassembled for easy installation, matched with Zone Nitro rear shocks. In the rear, you can select a 3-inch block to level the truck from front to rear or a 5-inch block to retain most of the factory rake, allowing you to tailor the stance and functionality of your lifted Ram.
Shop By Vehicle
Shop by vehicle
×
What fits my ride?
Shop By Vehicle
Shop By Vehicle
×
What fits my ride?
6 Inch Lift Kit | Ram 1500 (13-18) 4WD
SKU:
ZOND40F
×
- $1,744.28
- Unit price
- per
Features & Benefits
- This kit includes a 3" rear lift spring for a level rear end; a 5" rear lift spring is available in a "Tail High Rear End" version of this kit.
- Corrects suspension, steering, and drive-line geometry for great on-road handling and improved off-road performance.
- Heavy-duty differential skid slate improves off-road protection.
- High-strength, CNC machined, replacement steering knuckles improve strength while correcting steering angles.
- Top mount strut and preload spacers set ride height and maintain ride quality.
Recommended Tires & Wheels
(Trimming may be required)
- 37 x 12.5 with 17 x 9 and 4.5 in. Backspace
- 37 x 12.5 with 18 x 9 and 5 in. Backspace
- 37 x 12.5 with 20 x 9 and 5 in. Backspace
Rear Lift Option
These vehicles vary from 1" to 3" tail high from the factory. BDS offers both 3" and 5" rear kits. Be sure to measure your vehicle and order the appropriate rear lift height to level your truck.
- 3 Inch Coil Springs - Use if your vehicle is 3" tail high from the factory.
- 5 Inch Coil Springs - Use if your vehicle is level to 1" of tail high from the factory.
Rear Shock Option
Nitro Series
- Nitrogen-charged
- Twin-tube design
- 10-stage velocity-sensitive valving
- Dual-welded ends for increased strength
- Self-lubricating seals
- Black powder coat finish
FOX 2.0 Adventure Series
- 2-inch diameter steel body
- Internal floating piston (IFP) monotube design
- Large 5/8-inch hard chrome plated heat-treated alloy steel shaft
- Race-developed high-flow piston design
- Application-specific valving to maximize performance
- Long-lasting silver coated finish
- Does NOT work with all wheel drive (AWD) models.
- This kit is not recommended for TRX models. CV shaft vibration will occur on TRX models unless the TRX struts are replaced with standard struts. Instead, consider our 4" lift system for about 5" of TRX lift.
- Will NOT fit adjustable air suspension (air-ride) equipped models. Fitment: Does not fit eco-diesel models. Front drive shaft WILL fail prematurely.
- These trucks are typically between 1" and 3" tail high from the factory. Please measure your trucks factory front-to-back ride height and order the rear lift height to achieve the desired stance. If closer to 1" tail high from the factory order the 5" rear coils for a more level stance. If closer to 3" tail high from the factory order the 3" rear coils for a more level stance.
- Stock 17" wheels CAN NOT be re-installed.
- Stock 20" can be re-installed with factory tire.
